HOPE Hydraulic Breaker
HOPE hydraulic breaker
Compact and flexible,strong adaptability to working conditions
Powerful breaking, amazing efficiency
Precise control, highly efficient operation
Durable and reliable, worry-free maintenance
Description
1.Adjust the strike energy according to the hardness of material.
2.Piston adopt high-quality material 40CRINMO.After quenching and low tempering, it has high hardness, uniform structure, good wear resistance and high contact fatigue performance.
3.The steel body is made by the Alloy structural steel 20 CrMo.
4.High efficiency of reversing valve.High precision,strict roundness and concentricity quality inspection ensure that the valve is not stuck.
5.High-quality material such as 420CrMo is adopted on the chisel to support high strength,toughness,hardenabily,fatigue limit and multiple impact resistance after quenching and tempering treatment.
Specification
| ITEMS | TOP TYPE BREAKER |
| Models | 35 | 40 | 45 | 53 | 68 | 70 | 75 | 85 | 100 | 140 | 155 | 165 | 175 | 185 | 195 |
| Gross Weight(kg) | 95 | 95 | 130 | 195 | 290 | 290 | 400 | 620 | 900 | 1800 | 2740 | 2970 | 3730 | 4620 | 5410 |
| Length(mm) | 1080 | 1080 | 1239 | 1440 | 1638 | 1638 | 1864 | 2120 | 2380 | 2860 | 3100 | 3440 | 3650 | 3940 | 4020 |
| Driving Flow-Rate(litre/min) | 15-25 | 15-25 | 20-30 | 25-50 | 40-70 | 40-70 | 50-90 | 60-100 | 80-110 | 120-180 | 180-240 | 200-260 | 210-290 | 220-290 | 220-290 |
| Operating Pressure(Kg/cm2) | 90-120 | 90-120 | 90-120 | 90-120 | 95-130 | 95-130 | 120-150 | 130-160 | 150-170 | 160-180 | 160-180 | 160-180 | 160-180 | 180-220 | 180-220 |
| Striking Frequency(b.m.p) | 800-1400 | 800-1400 | 700-1200 | 600-1100 | 500-900 | 500-900 | 400-800 | 400-800 | 350-700 | 350-500 | 350-450 | 250-400 | 200-350 | 200-250 | 180-200 |
| Hose Diameter(inch) | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 | 3/4 | 1 | 5/4 | 5/4 | 5/4 | 5/4 | 5/4 |
| Rod Diameter(mm) | 35 | 40 | 45 | 53 | 68 | 70 | 75 | 85 | 100 | 140 | 155 | 165 | 175 | 185 | 195 |
| Applicable Vehicle Weight(ton) | 0.8-2.5 | 0.8-2.5 | 1.2-3 | 2-3.5 | 4-6 | 4-6 | 4.5-7 | 7-14 | 10-15 | 18-26 | 28-35 | 30-40 | 35-50 | 35-55 | 40-55 |
Support and Services
We provide technical support and services for our products. Our team of experienced engineers and technicians are available to answer any questions and provide assistance with any problems that may arise. Our services include installation, troubleshooting, maintenance, and repair of the product. We also provide training for operators and maintenance personnel to ensure the safe and effective operation of the equipment.
ABOUT US
After nearly ten years of development, Yantai Hope Precision Machinery Co., Ltd. process a professional and experienced technical research team. We produce our own brand by ourselves, the models of our products respectively are SB05, SB10,SB20,SB30,SB35,SB40,SB43,SB45,SB70,SB81 and other models.Our products are based on the quality of development. We use the highest quality raw materials and the most advanced manufacturing processes to provide the most durable quality products and best appearance and after-sale services.
